Broken Light Sensor Module KY-010

Broken Light Module KY-010, will trigger a signal when light between the sensor's gap is blocked. The KY-010 Broken Light Module consists of an optical emitter/detector in the front and two resistors (1 kΩ and 33 Ω) in the back. The sensor uses a beam of light between the emitter and detector to check if the path between both is being blocked by an opaque object.

Specifications:

• Operating Voltage: 3.3 ~ 5V
• Dimensions: 18.5mm x 15mm [0.728in x 0.591in]
