EMG Sensor

This Muscle sensor will measure the filtered and rectified electrical activity of a muscle, depending on the amount of activity in the selected muscle area. By detecting the electromyogram (EMG), measuring muscle activity has traditionally been used in medical research, microcontrollers, and integrated circuits.
The sensor will measure the electrical activity of the muscle output with a value between 0-5 volts, the output value will depend on the amount of muscle activity is selected.

Specifications:

• Gain: 1000
• Range: ±1.65mV (with VCC = 3.3V)
• Bandwidth: 10-400Hz
• Consumption: ~4mA
• Input Impedance: 100GOhm
• CMRR: 110dB
