FZ1035G Green Light Optical Fingerprint Reader Sensor Module
FZ1035G Green Light Optical Fingerprint Reader Sensor Module
Regular price
$32.00 USD
Regular price
Sale price
$32.00 USD
Unit price
/
per
Specifications:
- Supply voltage: DC 3.8-7.0V
- Operating current: <65mA
- Peak current: <95mA
- Fingerprint display time: <1.0 seconds
- Window area: 14.5*19.4mm
- Signature file: 256 bytes
- Template files: 512 bytes
- Storage capacity: 1000
- False acceptance rate (remote): <0.001% ( security level 3)
- False rejection rate (FRR): <1.0% (security level 3)
- Search time: <1.0 seconds (1:500 average)
- PC interface: UART (TTL logic level)
- Baud rate (UART): (9600 * N )bps (N = 1 ~ 12, N default 6, equal 57600bps)
- Operating environment temperature: -20°C to 50°C
- Relative humidity: 40% RH to 85% RH (non-condensing)
- Storage environment temperature: - 40°C to 85°C
- Relative humidity: <85%H (no condensation)
- Illumination: long light/flashing
- Dimensions (L * W * H): 56*20*20.5mm
Note:
There are basically two requirements to use the optical fingerprint sensor. First you will need to register the fingerprints - this means assigning their ID#'s to each print so you can query them later. Once you've saved all your prints, you can easily call the sensor and ask it to identify which ID (if any) was photographed.
You can register using windows software (easiest and neat, because it shows you a photo of the print) or with Arduino sketch (good for recording on the go or if you don't have a windows machine handy)
