GY-30 BH1750 Intensity Digital Light Sensor Module

This is a BH1750FVI ( GY30 GY 30 GY - 30 / BH 1750 ) light intensity sensor module with built-in a 16 bit AD converter generating digital signal. The data from this module is light intensity in lx (lux meter). It communicates with the micro-controller board through I2C bus.

Specifications:

• Working Voltage: 3.3V~6V
• I2C bus Interface with 2 alternative address (f/s Mode Support)
• Spectral responsibility is approximately human eye response
• Wide range and High resolution (1 ~ 65535 lx)
• Light source dependency is little. (ex. Incandescent Lamp, Fluorescent Lamp, Halogen Lamp, White LED, Sun Light)
• Adjustable measurement result for influence of optical window (It is possible to detect min. 0.11 lx, max. 100000 lx by using this function.) (1 ~ 65535 lx)
• The influence of infrared is very small.
• Small measurement variation (+/- 20%)
