GY-50 L3G4200D 3-Axis Gyroscope Sensor Module

GY-50 L3G4200D 3-Axis Gyroscope Sensor Module

Regular price $6.00 USD
Regular price Sale price $6.00 USD
Sale Sold out
Tax included.

GY - 50 ( GY50 GY 50) L3G4200D 3 - Axis Gyroscope Sensor Module is an angular velocity sensor board which contains a 3-axis gyroscope, providing you with very high resolution (16 bit) measurements at up to 2000 dps. The gyroscope measures how much the device is rotating around all three axis, the range is user selectable and so can be adjusted to suit your application. The module outputs data over either I2C or SPI. If you choose to use the device in I2C, there are handy soldering jumpers available on the board to choose the address.


  • Supply Voltage: 3V ~5V
  • I2C and SPI interfaces
  • 3 Axis Measurements
  • Adjustable resolution (250, 500, 2000 dps)
  • Very sensitive measurements (8.75mdps/LSB)
  • Anti-reverse IIC interface head to prevent again wrong hardware connection.
