Model |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Model |
DHI-LM22-B201S |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Size |
21.45" |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Panel type |
IPS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Aspect Ratio |
16:9 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
1920×1080 (FHD) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backlight |
LED |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Brightness/Luminance |
250 cd/㎡(max) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Contrast |
1000:1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Color |
16.7M(8bit) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Viewing Angle(H/V) |
178°(H)/178°(V) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Response time(typ.) |
5ms |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Refresh Rate |
75Hz (max) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Signals |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Input |
VGA×1, HDMI×1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output |
NO |
Speaker |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Speaker |
1Wx2 |
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
DC 12V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Consumption (Standard) |
22W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Consumption (Standby) |
≤0.5W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
2kg (4.4lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
3.12 kg (6.9lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bezel Width |
3.3mm(U/R/L) 15.2mm(B) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wall Mount |
75x75mm(3.0"x3.0") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimension with stand (W×H×D) |
492.7x284.0x48.4mm (20“x11.2”x1.9”) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Package(W×H×D) |
598x99x366mm (23.6“x4.0”x14.5”) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Work Environment |
Temperature |
0℃~40℃ (32°F~104°F) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Humidity |
10%~85% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Accessory |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Standard |
HDMI cable,Adapter,base |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE |
