Specifications: NRF
1- Ultra small: 15x29mm (including:built-in 2.4GHz antenna),for easy implementation into designs without additional hardware.
2- Low power consumption: Ultra low power consumption as low as 11.3mA transmitting, 13.5mA receiving at 2Mbps, 900nA in power down, and 26uA in standby.
3- Low operating voltage: 1.9 ~ 3.6V When using the nRF24L01 with an Arduino be sure to use the 3.3V output pin from the Arduino board to power the nRF24L01+ module
4- Communication range: 262 feet (80 meters) in ideal conditions.
5- Multi-channel:support six channels data reception.
6- Fast data transfer rate: 2Mbps (software setting range: 1Mbps or 2Mbps)
7- Multi frequency points:125 frequency points to meet the needs of multi point communication and frequency hopping communication.
8- The maximum transmit power:0dBm
