Electroslab

Power Supply 60V 5A

Power Supply 60V 5A

Tags
$100.00 USD
$100.00 USD
Sale Sold out
Taxes included.
Features:
  • Have complete operating protection function, over temperature protection, overload protection, and short circuit protection.
  • Small size, low ripple, light weight, high power density, highly efficient.
  • Voltage stabilization, current limiting, simple operation.
  • Constant pressure and constant current switch automatically.
  • Three LED display of voltage, current and power, high precision.
  • Temperature controlled fan heat dissipation, low noise, long life.
  • Four potentiometer more precise adjustment.
  • Dual voltage input and convenient choice.
  • Output Voltage ranges from 0 to rating voltage with continuous adjustment .
  • Output current ranges from 0 to rating current with continuous adjustment
  • AC 110v and 220v can work



Model

NPS605W

Output Power

300W

Output voltage

0~60V

Output current

0~5A

 Working environment

Input voltage: AC 230V/115V±10%, 50Hz/60Hz

Working temperature: 0℃～40℃
Relative humidity: <80%RH

Storage temperature: -10℃～70℃
Relative humidity: <70%RH

 Constant voltage CV

Voltage stability: 0.1%±3mV

Load stability: 0.2%±3mV

Ripple voltage: ≤0.5% Vp-p

0 to rated voltage continuously adjustable

 Constant current CC

Current stability: 0.1%±3mA

Load stability: 0.2%±3mA

Ripple current: ≤0.5% Vp-p

Recovery time: ≤500μS

Temperature coefficient: ≤100ppm/℃

0 to rated current continuously adjustable

 Display

0.4 inch red three digit display

Display accuracy: 0.5%±digits

Display resolution: voltage 0.01V, current 0.001A
