General | |
Availability: | currently available |
LAN / WAN Connectivity | |
WAN throughput: | 24 Mbps |
WAN ports: | 1 |
WAN port(s) type: | DSL/ISDN/POTS connector (RJ-11) |
LAN ports: | 4 |
LAN ports type: | 10/100 Base-TX (RJ-45) |
LAN ports auto cross-over: | ![]() |
Router | |
NAT routing: | ![]() |
Multihomed: | ![]() |
DHCP server: | ![]() |
DHCP client: | ![]() |
DHCP relay: | ![]() |
Dynamic DNS client: |
![]() |
QoS: | ![]() |
UPnP: | ![]() |
Routing Protocols: |
RIP v1 (static routing, RFC 1058) RIP v2 (dynamic routing, RFC1389) IGMP Multicast (RFC 1112) |
DSL | |
DSL compliance: |
ADSL1 (G.dmt 992.1, G.lite 992.2, G.hs 994.1, DMT T1.413) ADSL2 (G.992.3, G.lite.bis 992.4) RE-ADSL2 (G.992.3 Annex L) ADSL2+ (G.992.5) ADSL2+M (G.992.5 Annex M) |
PPPoE client: | ![]() |
PPPoA client: | ![]() |
Wireless | |
Maximum Wireless Speed: | 300 Mbps (Wi-Fi 4) |
WiFi standards supported: |
802.11b (Wi-Fi 1) 802.11g (Wi-Fi 3) 802.11n (Wi-Fi 4) |
Wifi security/authentication: | WEP WPA (TKIP) WPA2 (AES) |
WiFi modes: | Access point |
external antenna(s): | 2 |
WPS (Wi-Fi Protected Setup): | ![]() |
VPN | |
IPSec | |
IPSec passthrough: | ![]() |
L2TP | |
L2TP passthrough: | ![]() |
PPTP | |
PPTP passthrough: | ![]() |
Firewall | |
SPI firewall: | ![]() |
DoS / DDoS protection: | ![]() |
Device Management | |
Default IP address: | 192.168.1.1 |
Default admin username: | admin |
Default admin password: | admin |
Administration: |
Web-based (LAN) Quick Setup Wizard Telnet / CLI |
