TP-Link
Tp-Link 300mbps Wireless N VDSL/ADSL Modem Router Td-W9970
Tp-Link 300mbps Wireless N VDSL/ADSL Modem Router Td-W9970
Tags
Regular price
$33.00 USD
Regular price
Sale price
$33.00 USD
Unit price
/
per
Sale
Sold out
Taxes included.
No reviews
Couldn't load pickup availability
HARDWARE FEATURES
Interface
4 10/100Mbps RJ45 Ports
1 RJ11 Port
1 USB 2.0 Port
Ports
1× 10/100 Mbps LAN/WAN Port, 3× 10/100 Mbps LAN ports, 1×
RJ11 port, 1× USB 2.0 Port
Button
1 Power On/Off Button
1 WPS/RESET Button
1 Wi-Fi On/Off Switch
External Power Supply
12VDC/1A
IEEE Standards
IEEE 802.3, 802.3u
VDSL2 Standards
ITU-T G.993.2
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP）
ADSL Standards
Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT)
ITU-T G.994.1 (G.hs)
ITU-T G.995.1
ADSL2 Standards
ITU-T G.992.3 (G.dmt.bis)
ADSL2+ Standards
ITU-T G.992.5
Dimensions ( W x D x H )
7.7*5.1*1.4 in. (195×130×36mm)
Antenna
2 × 4dBi Fixed Omni-Directional Antennas
Antenna Type
Omni directional, Fixed
Antenna Gain
2 x 5dBi
WIRELESS FEATURES
Wireless Standards
IEEE 802.11b, 802.11g, 802.11n
Frequency
2.400-2.4835GHz
Signal Rate
300 Mbps at 2.4 GHz
Transmit Power
<20dBm(EIRP)
Wireless Functions
Enable/Disable Wireless Radio, WMM,
Wireless Statistics
Wireless Security
Support 64/128 bit WEP, WPA /WPA2, WPA-PSK/WPA2-PSK
Wireless MAC Filtering
SOFTWARE FEATURES
Quality of Service
WMM, Bandwidth Control (IP QoS)
Security
NAT Firewall,
SPI Firewall,
MAC / IP / URL Filtering
IPv6
IPv6 and IPv4 dual stack
Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4
Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6
Operating Modes
DSL Modem Router, 3G/4G Router, Wireless Router
Management
Web Based Configuration(HTTP),
Remote management,
Telnet management,
Command Line Interface,
SSL for TR-069,
SNMP V1/V2C,
Web Based Firmware Upgrade,
CWMP(TR-069),
Diagnostic Tools
DHCP
Server, Client, DHCP Client List, Address Reservation, DHCP Relay
Port Forwarding
Virtual server, Port Triggering, UPnP, DMZ, Manage Control
Dynamic DNS
DynDns, NO-IP
VPN Pass-Through
PPTP, L2TP, IPSec Pass-through
Protocols
Supports IPv4 and IPv6
ATM/PPP Protocols
ATM Forum UNI3.1/4.0
PPP over ATM (RFC 2364)
PPP over Ethernet (RFC2516)
IPoA (RFC1577/2225)
PVC - Up to 8 PVCs
Advanced Features
Ethernet WAN (EWAN)
Guest Network, Wireless Schedule
Parent Control
Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt;
Dynamic Host Configuration Protocol (DHCP), DHCP relay;
Network Address Translation (NAT);
PVC/Ethernet Port Grouping
Static Routing, RIP v1/v2 (optional);
DNS Relay, DDNS,
IGMP snooping V1/2
IGMP Multicast,
UPnP
USB Sharing
Storage Sharing
FTP Server
Media Server
Print Server
Guest Network
2.4 GHz Guest Network
IGMP
IGMP snooping V1/V2/V3
IGMP Multicast
IPSec VPN
10 IPSec VPN Tunnels
LAN-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
MD5, SHA1 Authentication Algorithm
Manual, IKE Key Management Mode
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)
OTHERS
Certification
CE, RoHS
Package Contents
TD-W9970
External Splitter
RJ-11 Telephone Line
RJ-45 Ethernet Cable
Quick Installation Guide
Resource CD
Power Adapter
System Requirements
Windows 10/8.1/8/7/Vista/XP or Mac OS or Linux-based operating system
Environment
Operating Temperature: 0~40 (32~104)
Storage Temperature: -40~70 (-40~158)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Share
View full details
Regular price
$33.00 USD
Regular price
Sale price
$33.00 USD
Unit price
/
per
No reviews
Couldn't load pickup availability
| HARDWARE FEATURES | |
|---|---|
| Interface | 4 10/100Mbps RJ45 Ports 1 RJ11 Port 1 USB 2.0 Port |
| Ports | 1× 10/100 Mbps LAN/WAN Port, 3× 10/100 Mbps LAN ports, 1× RJ11 port, 1× USB 2.0 Port |
| Button | 1 Power On/Off Button 1 WPS/RESET Button 1 Wi-Fi On/Off Switch |
| External Power Supply | 12VDC/1A |
| IEEE Standards | IEEE 802.3, 802.3u |
| VDSL2 Standards | ITU-T G.993.2 ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP） |
| ADSL Standards | Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT) ITU-T G.994.1 (G.hs) ITU-T G.995.1 |
| ADSL2 Standards | ITU-T G.992.3 (G.dmt.bis) |
| ADSL2+ Standards | ITU-T G.992.5 |
| Dimensions ( W x D x H ) | 7.7*5.1*1.4 in. (195×130×36mm) |
| Antenna | 2 × 4dBi Fixed Omni-Directional Antennas |
| Antenna Type | Omni directional, Fixed |
| Antenna Gain | 2 x 5dBi |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11b, 802.11g, 802.11n |
| Frequency | 2.400-2.4835GHz |
| Signal Rate | 300 Mbps at 2.4 GHz |
| Transmit Power | <20dBm(EIRP) |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security | Support 64/128 bit WEP, WPA /WPA2, WPA-PSK/WPA2-PSK Wireless MAC Filtering |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | WMM, Bandwidth Control (IP QoS) |
| Security | NAT Firewall, SPI Firewall, MAC / IP / URL Filtering |
| IPv6 | IPv6 and IPv4 dual stack Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4 Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6 |
| Operating Modes | DSL Modem Router, 3G/4G Router, Wireless Router |
| Management | Web Based Configuration(HTTP), Remote management, Telnet management, Command Line Interface, SSL for TR-069, SNMP V1/V2C, Web Based Firmware Upgrade, CWMP(TR-069), Diagnostic Tools |
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| Port Forwarding | Virtual server, Port Triggering, UPnP, DMZ, Manage Control |
| Dynamic DNS | DynDns, NO-IP |
| VPN Pass-Through | PPTP, L2TP, IPSec Pass-through |
| Protocols | Supports IPv4 and IPv6 |
| ATM/PPP Protocols | ATM Forum UNI3.1/4.0 PPP over ATM (RFC 2364) PPP over Ethernet (RFC2516) IPoA (RFC1577/2225) PVC - Up to 8 PVCs |
| Advanced Features | Ethernet WAN (EWAN) Guest Network, Wireless Schedule Parent Control Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt; Dynamic Host Configuration Protocol (DHCP), DHCP relay; Network Address Translation (NAT); PVC/Ethernet Port Grouping Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS, IGMP snooping V1/2 IGMP Multicast, UPnP |
| USB Sharing | Storage Sharing FTP Server Media Server Print Server |
| Guest Network | 2.4 GHz Guest Network |
| IGMP | IGMP snooping V1/V2/V3 IGMP Multicast |
| IPSec VPN | 10 IPSec VPN Tunnels LAN-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm MD5, SHA1 Authentication Algorithm Manual, IKE Key Management Mode Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) |
| OTHERS | |
|---|---|
| Certification | CE, RoHS |
| Package Contents | TD-W9970 External Splitter RJ-11 Telephone Line RJ-45 Ethernet Cable Quick Installation Guide Resource CD Power Adapter |
| System Requirements | Windows 10/8.1/8/7/Vista/XP or Mac OS or Linux-based operating system |
| Environment | Operating Temperature: 0~40 (32~104) Storage Temperature: -40~70 (-40~158) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
