UNI-T UT206B 1000A Digital Clamp Meter
UNI-T UT206B 1000A Digital Clamp Meter
Tags
Regular price
$70.00 USD
Regular price
Sale price
$70.00 USD
Unit price
/
per
Sale
Sold out
Taxes included.
No reviews
Couldn't load pickup availability
Specifications
Range
UT206B
AC current (A)
1000A
±(2%+5)
AC current frequency response
50Hz~60Hz
Inrush current (A)
1000A
±(10%+10)
AC voltage (V)
1000V
±(1.2%+3)
DC voltage (V)
1000V
±(0.5%+5)
Low pas filter (LPF ACV)
1000V
±(2%+5)
AC voltage frequency response
40Hz~400Hz
LoZ ACV
1000V
±(2%+5)
Resistance (Ω)
60MΩ
±(1%+2)
Capacitance (F)
60mF
±(4%+5)
Temperature
-40℃~1000℃
±(1%+2)
-40℉~1832℉
±(1%+4)
Low voltage frequency (Hz)
10Hz~1MHz
±(0.1%+3)
Duty cycle (%)
10%~90%
±(2.6%+7)
Analog bar
31
Flexible current probe (optional)
Extends up to 3000A
√
Zero mode
Display count
6000
Jaw opening
42mm
General Characteristics
Power
1.5V battery (R03) x 3
Display
43mm x 45mm
Product net weight
UT205E/UT206B: 465g
Product size
272mm x 81mm x 43.5mm
Standard accessories
Test leads, batteries, point contact temperature probe (UT206B/UT208B), English manual
Standard individual packing
Gift box, carrying bag
Share
View full details
Regular price
$70.00 USD
Regular price
Sale price
$70.00 USD
Unit price
/
per
No reviews
Couldn't load pickup availability
| Specifications | Range | UT206B |
| AC current (A) | 1000A | ±(2%+5) |
| AC current frequency response | 50Hz~60Hz | |
| Inrush current (A) | 1000A | ±(10%+10) |
| AC voltage (V) | 1000V | ±(1.2%+3) |
| DC voltage (V) | 1000V | ±(0.5%+5) |
| Low pas filter (LPF ACV) | 1000V | ±(2%+5) |
| AC voltage frequency response | 40Hz~400Hz | |
| LoZ ACV | 1000V | ±(2%+5) |
| Resistance (Ω) | 60MΩ | ±(1%+2) |
| Capacitance (F) | 60mF | ±(4%+5) |
| Temperature | -40℃~1000℃ | ±(1%+2) |
| -40℉~1832℉ | ±(1%+4) | |
| Low voltage frequency (Hz) | 10Hz~1MHz | ±(0.1%+3) |
| Duty cycle (%) | 10%~90% | ±(2.6%+7) |
| Analog bar | 31 | |
| Flexible current probe (optional) | Extends up to 3000A | √ |
| Zero mode | ||
| Display count | 6000 | |
| Jaw opening | 42mm | |
| General Characteristics | ||
| Power | 1.5V battery (R03) x 3 | |
| Display | 43mm x 45mm | |
| Product net weight | UT205E/UT206B: 465g | |
| Product size | 272mm x 81mm x 43.5mm | |
| Standard accessories | Test leads, batteries, point contact temperature probe (UT206B/UT208B), English manual | |
| Standard individual packing | Gift box, carrying bag | |
