74HC595N 8-Bit Shift

74HC595N 8-Bit Shift

Regular price $0.50 USD
Regular price Sale price $0.50 USD
Sale Sold out
Tax included.
The 74595 is an high speed CMOS device. An eight bit shift register accpets data from the serial input (DS) on each positive transition of the shift register clock (SHCP). When asserted low the reset function ( ) sets all shift register values to zero and is indepent of all clocks. Data from the input serial shift register is placed in the output register with a rising pulse on the storages resister clock (STCP). With the output enable ( E asserted low the 3-state outputs Q0-Q7 become active and present th. All registers capture data on rising edge and change output on the falling edge. If both clocks are connected together the input shift register is always one clock cycle ahead of the output register.
