Electroslab

DHT22 Digital Temperature & Humidity Sensor Module

DHT22 Digital Temperature & Humidity Sensor Module

Regular price $6.00 USD
Regular price Sale price $6.00 USD
Sale Sold out
Tax included.

The DHT 22 is a commonly used Temperature and humidity sensor. The sensor comes with a dedicated NTC to measure temperature and an 8-bit microcontroller to output the values of temperature and humidity as serial data. The sensor is also factory calibrated and hence easy to interface with other microcontrollers.

The sensor can measure temperature from -40°C to 80°C and humidity from 0% to 100% with an accuracy of ±1°C and ±1%.

Specifications:

  • Operating Voltage: 3.5V to 5.5V
  • Operating current: 0.3mA (measuring) 60uA (standby)
  • Output: Serial data
  • Temperature Range: -40°C to 80°C
  • Humidity Range: 0% to 100%
  • Resolution: Temperature and Humidity both are 16-bit
  • Accuracy: ±0.5°C and ±1%
