L298N 2-Way DC Motor Driver

L298N 2-Way DC Motor Driver

Tags
Regular price $2.50 USD
Regular price Sale price $2.50 USD
Sale Sold out
Taxes included.

This motor driver module is ideal for use in battery-powered smart car, toy cars, robots. Supply voltage 2V ~ 10V, can drive two DC motors or a 4-wire 2-phase stepper motors ,can achieve forward rotation or reverse rotation, it is possible to adjust the rotation speed. Each can provide continuous current of 1.5A, peak current up to 2.5A, thermal protection and can be automatically restored.

Features:

  • Dual H-bridge motor driver, can drive two DC motors or a 4-wire two-phase stepper motor.
  • The module supply voltage 2V-10V.
  • Signal input voltage 1.8-7V.
  • Single Operating current 1.5A, peak current up to 2.5A, low standby current (less than 0.1uA).
  • Built-in common conduction circuit, when the input pin is left floating, the motor does not malfunction.
  • Built-in thermal protection circuit with hysteresis effects (TSD), without worrying about the motor stall.
