MQ-135 Air Quality Sensor Detection Module

The MQ135 ( MQ - 135 ) Gas sensors are used in air quality control equipments and are suitable for detecting or measuring of NH3, NOx, Alcohol, Benzene, Smoke, CO2. The MQ-135 sensor module comes with a Digital Pin which makes this sensor operate even without a microcontroller and that comes in handy when you are only trying to detect one particular gas.  If you need to measure the gases in PPM the analog pin needs to be used. The analog pin is TTL driven and works on 5V and so can be used with most common microcontrollers.

Specifications:

• Wide detecting scope
• Fast response and High sensitivity
• Stable and long life
• Operating Voltage is +5V
• Detect/Measure NH3, NOx, alcohol, Benzene, smoke, CO2, etc.
• Analog output voltage: 0V to 5V
• Digital output voltage: 0V or 5V (TTL Logic)
• Preheat duration 20 seconds
• Can be used as a digital or analog sensor
• The Sensitivity of Digital pin can be varied using the potentiometer
