UNI-T UT139S True RMS Digital Multimeters
UNI-T UT139S True RMS Digital Multimeters
Tags
Regular price
$75.00 USD
Regular price
Sale price
$75.00 USD
Unit price
/
per
Sale
Sold out
Taxes included.
No reviews
Couldn't load pickup availability
Specifications
Range
UT139S
DC voltage (V)
600V
±(0.5%+2)
AC voltage (V)
600V
±(0.8%+3)
DC current (A)
10A
±(0.7%+2)
AC current (A)
10A
±(1%+3)
Resistance (Ω)
20MΩ
40MΩ
60MΩ
±(0.8%+2)
Capacitance (F)
99.99mF
±(4%+5)
Frequency (Hz)
10Hz~10MHz
±(0.1%+4)
Temperature (°C)
-40°C~1000°C
±(1%+4)
Temperature (°F)
-40°F~1832°F
±(1.5%+5)
Features
Display count
6000
Auto range/Manual range
√
/True RMS
Bandwidth (Hz)
45Hz~400Hz
NCV/Continuity buzzer
√
Duty cycle
0.1%~99.9%
√
Diode
Around 3V
LPF/LoZ (ACV)
√
Analog bar
√
General Characteristics
Power
1.5V battery (R6) x 2
Display
58mm x 36mm
Product color
Red and grey
Product net weight
UT139S: 345g
Product size
170mm x 80mm x 48mm
Standard accessories
UT139C/S: Batteries, test leads, temperature probe
Standard individual packing
Gift box, English manual
Share
View full details
Regular price
$75.00 USD
Regular price
Sale price
$75.00 USD
Unit price
/
per
No reviews
Couldn't load pickup availability
| Specifications | Range | UT139S |
| DC voltage (V) | 600V | ±(0.5%+2) |
| AC voltage (V) | 600V | ±(0.8%+3) |
| DC current (A) | 10A | ±(0.7%+2) |
| AC current (A) | 10A | ±(1%+3) |
| Resistance (Ω) | 20MΩ | |
| 40MΩ | ||
| 60MΩ | ±(0.8%+2) | |
| Capacitance (F) | 99.99mF | ±(4%+5) |
| Frequency (Hz) | 10Hz~10MHz | ±(0.1%+4) |
| Temperature (°C) | -40°C~1000°C | ±(1%+4) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+5) |
| Features | ||
| Display count | 6000 | |
| Auto range/Manual range | √ | |
| /True RMS | ||
| Bandwidth (Hz) | 45Hz~400Hz | |
| NCV/Continuity buzzer | √ | |
| Duty cycle | 0.1%~99.9% | √ |
| Diode | Around 3V | |
| LPF/LoZ (ACV) | √ | |
| Analog bar | √ | |
| General Characteristics | ||
| Power | 1.5V battery (R6) x 2 | |
| Display | 58mm x 36mm | |
| Product color | Red and grey | |
| Product net weight | UT139S: 345g | |
| Product size | 170mm x 80mm x 48mm | |
| Standard accessories | UT139C/S: Batteries, test leads, temperature probe | |
| Standard individual packing | Gift box, English manual | |
