UNI-T UT181A True RMS Datalogging Multimeter
UNI-T UT181A True RMS Datalogging Multimeter
Tags
Regular price
$350.00 USD
Regular price
Sale price
$350.00 USD
Unit price
/
per
Sale
Sold out
Taxes included.
No reviews
Couldn't load pickup availability
Specifications
Range
UT181A
DC voltage (V)
1000V
±(0.025%+5)
AC voltage (V)
1000V
±(0.3%+30)
DC current (A)
10A
±(0.08%+10)
AC current (A)
10A
±(0.6%+20)
Resistance (Ω)
60MΩ
±(0.05%+2)
Admittance (nS)
60nS
±(2%+10)
Capacitance (F)
60mF
±(2%+5)
Frequency (Hz)
10Hz~60MHz
±(0.01%+5)
Temperature (°C)
-40°C~1000°C
±(1%+30)
Temperature (°F)
-40°F~1832°F
±(1.5%+50)
Features
Display count
60000
Auto/Manual range
√
Bandwidth (Hz)
100kHz
√
AC+DC/Continuity buzzer
√
Low pass filter
1kHz
√
dBV/dBm
√
Diode
Around 3V
√
Duty cycle
10%~90%
√
Dual temperature measurement
T1, T2, T1-T2, T2-T1
√
Data hold/Peak hold
√
Relative mode
√
Data logging
20000
√
Trend capture
√
MAX/MIN/AVG
√
Data time display/Data comparison
√
Backlight adjustment
√
Analog bar graph/USB interface
√
Mis-plug alarm
√
Battery indication/Auto power off
√
Rechargeable battery
√
Input protection
√
Input impedance for DCV
≥10MΩ
√
General Characteristics
Power
Li-ion battery: 7.4V 2000mAh
Display
3.5-inch 64K color TFT LCD (320 x 240)
Product color
Red and grey
Product net weight
638.6g
Product size
225mm x 103mm x 59mm
Standard accessories
Battery, test leads, temperature adaptor socket,
point contact temperature probes, power adaptor socket, power adaptor, PC software CD, USB interface cable
Standard individual packing
Gift box, carrying bag, English manual
Optional accessory
Bluetooth adaptor (UT-D07)
Share
View full details
Regular price
$350.00 USD
Regular price
Sale price
$350.00 USD
Unit price
/
per
No reviews
Couldn't load pickup availability
| Specifications | Range | UT181A |
| DC voltage (V) | 1000V | ±(0.025%+5) |
| AC voltage (V) | 1000V | ±(0.3%+30) |
| DC current (A) | 10A | ±(0.08%+10) |
| AC current (A) | 10A | ±(0.6%+20) |
| Resistance (Ω) | 60MΩ | ±(0.05%+2) |
| Admittance (nS) | 60nS | ±(2%+10) |
| Capacitance (F) | 60mF | ±(2%+5) |
| Frequency (Hz) | 10Hz~60MHz | ±(0.01%+5) |
| Temperature (°C) | -40°C~1000°C | ±(1%+30) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+50) |
| Features | ||
| Display count | 60000 | |
| Auto/Manual range | √ | |
| Bandwidth (Hz) | 100kHz | √ |
| AC+DC/Continuity buzzer | √ | |
| Low pass filter | 1kHz | √ |
| dBV/dBm | √ | |
| Diode | Around 3V | √ |
| Duty cycle | 10%~90% | √ |
| Dual temperature measurement | T1, T2, T1-T2, T2-T1 | √ |
| Data hold/Peak hold | √ | |
| Relative mode | √ | |
| Data logging | 20000 | √ |
| Trend capture | √ | |
| MAX/MIN/AVG | √ | |
| Data time display/Data comparison | √ | |
| Backlight adjustment | √ | |
| Analog bar graph/USB interface | √ | |
| Mis-plug alarm | √ | |
| Battery indication/Auto power off | √ | |
| Rechargeable battery | √ | |
| Input protection | √ | |
| Input impedance for DCV | ≥10MΩ | √ |
| General Characteristics | ||
| Power | Li-ion battery: 7.4V 2000mAh | |
| Display | 3.5-inch 64K color TFT LCD (320 x 240) | |
| Product color | Red and grey | |
| Product net weight | 638.6g | |
| Product size | 225mm x 103mm x 59mm | |
| Standard accessories | Battery, test leads, temperature adaptor socket, | |
| point contact temperature probes, power adaptor socket, power adaptor, PC software CD, USB interface cable | ||
| Standard individual packing | Gift box, carrying bag, English manual | |
| Optional accessory | Bluetooth adaptor (UT-D07) | |
