UNI-T UT373 Non-Contact Tachometer
UNI-T UT373 Non-Contact Tachometer
Tags
Regular price
$30.00 USD
Regular price
Sale price
$30.00 USD
Unit price
/
per
Sale
Sold out
Taxes included.
No reviews
Couldn't load pickup availability
Specifications
Range
Resolution
Accuracy
RPM measurement
10.0~9999.9RPM
0.1
±(0.04%+2)
10000~99999RPM
1
Counting measurement
0~99999 counts
1
±1
Features
Auto range
√
Auto power off
√
Low battery indication
√
Laser-on indication
√
Data hold
√
MAX/MIN
√
Rotating speed/count function switching
√
Overload indication
√
LCD backlight
√
Refresh rate
1s to 7s (>120rpm for 1s)
Sensor type
Photodiode and laser tube
Target distance
50mm~200mm
Measuring angle
±30° from perpendicular
Drop test
1m
General Characterisitics
Power
1.5V battery (R03) x 3
Display
5-digit segment code; 99999 max display
Product color
Red and grey
Product net weight
85g (excluding battery)
Product size
183.8mm x 56mm x 34mm
Standard accessories
Batteries, reflective tape
Standard individual packing
Bubble bag, gift box, English manual
Share
View full details
Regular price
$30.00 USD
Regular price
Sale price
$30.00 USD
Unit price
/
per
No reviews
Couldn't load pickup availability
| Specifications | Range | Resolution | Accuracy |
| RPM measurement | 10.0~9999.9RPM | 0.1 | ±(0.04%+2) |
| 10000~99999RPM | 1 | ||
| Counting measurement | 0~99999 counts | 1 | ±1 |
| Features | |||
| Auto range | √ | ||
| Auto power off | √ | ||
| Low battery indication | √ | ||
| Laser-on indication | √ | ||
| Data hold | √ | ||
| MAX/MIN | √ | ||
| Rotating speed/count function switching | √ | ||
| Overload indication | √ | ||
| LCD backlight | √ | ||
| Refresh rate | 1s to 7s (>120rpm for 1s) | ||
| Sensor type | Photodiode and laser tube | ||
| Target distance | 50mm~200mm | ||
| Measuring angle | ±30° from perpendicular | ||
| Drop test | 1m | ||
| General Characterisitics | |||
| Power | 1.5V battery (R03) x 3 | ||
| Display | 5-digit segment code; 99999 max display | ||
| Product color | Red and grey | ||
| Product net weight | 85g (excluding battery) | ||
| Product size | 183.8mm x 56mm x 34mm | ||
| Standard accessories | Batteries, reflective tape | ||
| Standard individual packing | Bubble bag, gift box, English manual | ||
